Custom service
1, power, current, speed, efficiency, power factor
2, shell protection structure type, protection grade
3. Installation structure and type
4. Cooling mode
5. Power grade and installation size
6, winding allowable temperature rise
7, operating conditions: altitude, ambient temperature, minimum
temperature, Power supply voltage, frequency, no-load current
value, etc
Can be customized according to customer requirements
| Performance |
| Parameter | Remarks | Symbol | Unit | EL32-03 | EL32-06 |
| Winding Type | | | | S | S |
| Motor type | 3 phases synchronous Ironless, 45Vacrms (60Vdc) |
| Peak Force@20℃/s ↑ | Magnet@25℃ | Fp | N | 46 | 92 |
| Continuous Force | Coil@110℃ | Fc | N | 11.5 | 23 |
| Maximum Speed | 60V | Vmax | m/s | 5 | 5 |
| Motor Force Constant | Mount. Sfc.@20℃ | K | N/Arms | 7.3 | 7.3 |
| Motor Constant | Coils@25℃ | S | N²/W | 7.5 | 15 |
|
| Electrical |
| Peak Current | Magnet@25℃ | Ip | Arms | 6.3 | 12.6 |
| Continuous Current | Coil@110℃ | Ic | Arms | 1.6 | 3.2 |
| Back EMF | Phase-Phase peak | Bemf | V/M/S | 6 | 6 |
| Resistance Per Phase | Coil@25℃ | Rph | Ω | 2.4 | 1.175 |
| Induction Per Phase | I<0.63lp | Lph | mh | 0.8 | 0.4 |
| Electrical Time Constant | Coil@25℃ | τe | ms | 0.355 | 0.355 |
| Power Loss | All coils | Pc | W | 24 | 47 |
|
| Thermal |
| Thermal R. | Coils to mount. Sfc. | Rth | ºC/W | 3.2 | 1.6 |
| Temp. Sensor | Temperature Cut-off | NTC Optional |
|
| Mechanical |
| Coil Unit Weight | ex.cables | W | Kg | 0.04 | 0.06 |
| Coil Unit Length | ex.cables | L | mm | 49 | 89 |
| Motor Attraction Force | Rms@0A | Fa | N | 0 | 0 |
| Magnet Pitch | N-N | τ | mm(AWG) | 24 | 16.5 |
| Cable Mass | | M | Kg/m | 0.065 | 0.065 |
| Cable Type( Flex.cable) | length 1m | d | mm(AWG) | 4.5(24) | 4.5(24) |
| Power Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | 4.5(3*0.3mm2) |
| Sensor Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | customizable |
| Cable life | Minimum | | Cycles | ≥12,000,000 |
| Bending Radius Static | Minimum | | mm | ≥4xφ |
| Bending Radius Dynamic | Minimum | | mm | ≥7.5xφ |
Product dimension drawing:
FAQ:
Q: What’s your MOQ?
A: 1pcs
Q: How to order your encoder?
A: Contact us, or email us, we will reply you as soon as possible.
Q: Can you product ship to our country?
A: Yes, please advise your destination and zip code, we will check
freight cost for you immediately.
Q: How to get the latest price?
A: Contact us and tell me the encoder model selection.
Q: How to select a right encoder model?
A: A right encoder model is based on different applications and
parameters, you could contact us for technical support if you have
any query.
Q: Do you offer technical support?
A: Yes, we have professional technician who can solve all your
doubts.
Q: Can you factory offer a sample?
A: Yes, sample can be provided.
Q: How to pay for a sample?
A: Currently, our factory accept L/C, T/T, Western Union.
Q: What’s your encoder product guarantee policy?
A: 1 year quality warranty and life-long technical support.
If you have any doubt on selecting the model, you are welcome to
contact us for more assistant.
